7. Separate the shift cable end (A) from the shift cable end holder (B).

Fig. 350: Identifying Shift Cable And Shift Cable End Holder
Courtesy of AMERICAN HONDA MOTOR CO., INC.

8. Rotate the socket holder (A) on the shift cable (B) a quarter turn; the tab (C) on the socket holder will be

in the opening (D) of the shift cable bracket (E). Then slide the holder to remove the shift cable from the
shift cable bracket. Do not remove the shift cable by twisting the shift cable guide (F) and damper (G).

Fig. 351: Rotating Socket Holder On Shift Cable
Courtesy of AMERICAN HONDA MOTOR CO., INC.

9. Remove the shift lever mounting bolts.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



Fig. 352: Identifying Shift Lever Mounting Bolts With Torque Specification
Courtesy of AMERICAN HONDA MOTOR CO., INC.

10. Remove the shift lever mounting bolt (A), and remove the shift cable bracket (B).

Fig. 353: Identifying Shift Lever Mounting Bolt And Shift Cable Bracket With Torque
Specifications
Courtesy of AMERICAN HONDA MOTOR CO., INC.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



11. Remove the D3 switch/shift lock solenoid connector (C), then disconnect the connector.

12. Check for continuity between D3 switch/shift lock solenoid connector terminals No. 1 and No. 2 while

pressing the D3 switch and when the switch is released. There should be continuity while pressing the D3
switch and no continuity when the switch is released.

13. If the D3 switch works properly, connect the connector and install the removed parts. If the switch is

faulty, go to step 14, and replace the switch.

14. Remove the shift lever assembly.

15. Pry out the D3 switch cover (A), and remove it.

Fig. 354: Prying Out D3 Switch Cover
Courtesy of AMERICAN HONDA MOTOR CO., INC.

16. Remove the D3 switch (A) by expanding its locks, and remove the screws (B), shift lever button (C),

spring (D), and shift lever knob (E).

Fig. 355: Identifying Screws, Shift Lever Button, Spring And Shift Lever Knob
Courtesy of AMERICAN HONDA MOTOR CO., INC.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element



17. Remove the A/T gear position indicator panel light socket (A), then separate the A/T gear position

indicator panel (B) from the shift lever bracket (C).

Fig. 356: Identifying A/T Gear Position Indicator Panel And Shift Lever Bracket
Courtesy of AMERICAN HONDA MOTOR CO., INC.

18. Pry the lock tabs on the back of the D3 switch/shift lock solenoid connector (A), and remove the back

cover (B).

Fig. 357: Prying Lock Tabs
Courtesy of AMERICAN HONDA MOTOR CO., INC.

19. Remove the terminal (C) from the connector by pushing the lock tab (D) up in the connector using a thin

blade screwdriver (E). Remove all four terminals.

20. Remove the D3 switch harness clamp from the shift lever bracket and from the harness, and pull the D3

switch harness out to remove the shift lever assembly.

21. Insert the new D3 switch harness (A) into the shift lever ring (B), and route the harness through the

groove (C) of the shift lever (D) into the hole (E). Do not pinch the harness.



2007 Honda Element EX

2007-2008 TRANSMISSION Automatic Transmission - Element
