1. Turn the ignition switch ON (II). 2. Clear the DTC with the HDS. 3. Start the engine in the P position, and wait for at least 1 second. 4. Check for DTCs with the HDS. Is DTC P0974 indicated? YES -Go to step 8. NO -Go to step 5. 5. Select Shift Solenoid A in Miscellaneous Test Menu, and test shift solenoid valve A with the HDS. Is a clicking sound heard? YES -Go to step 6. NO -Go to step 8. 6. Start the engine in the P position, and wait for at least 1 second. 7. Monitor the OBD STATUS for P0974 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES -Go to step 8. NO -If the screen indicates PASSED, intermittent failure, the system is OK at this time. Check for poor 5 . 8. Turn the ignition switch OFF. 9. Jump the SCS line with the HDS. 10. Disconnect PCM connectors A (31P) and C (22P). 11. Measure the resistance between PCM connector terminals C6 and A9. NOTE: Before you troubleshoot, record all freeze data and any on-board This code is caused by an electrical circuit problem and cannot be caused
2007 Honda Element EX 2007-2008 TRANSMISSION Automatic Transmission - Element
|
