YES -If the PCM was updated, troubleshooting is complete. If the PCM was substituted, replace the NO -If the screen indicates FAILED, check for poor connections or loose terminals between A/T clutch DTC P0963: PROBLEM IN A/T CLUTCH PRESSURE CONTROL SOLENOID VALVE A 1. Turn the ignition switch ON (II). 2. Clear the DTC with the HDS. 3. Start the engine, and wait for at least 1 second. 4. Check for DTCs with the HDS. Is DTC P0963 indicated? YES -Go to step 8. NO -Go to step 5. 5. Select Clutch Pressure Control Solenoid Control in Miscellaneous Test Menu, and test A/T clutch pressure control solenoid valve A with the HDS. Does the screen indicate NORMAL? YES -Go to step 6. NO -Go to step 8. 6. Command A/T clutch pressure control solenoid valve A at 0.2 A in Clutch Pressure Control Solenoid Control menu. 7. Monitor the OBD STATUS for P0963 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES -Go to step 8. NOTE: Before you troubleshoot, record all freeze data and any on-board This code is caused by an electrical circuit problem and cannot be caused
2007 Honda Element EX 2007-2008 TRANSMISSION Automatic Transmission - Element
|
