Fig. 252: Identifying Front Passenger's Airbag 4P Connector

4. Remove the passenger's dashboard upper panel dashboard tray cover (see PASSENGER'S

DASHBOARD UPPER PANEL AND DASHBOARD TRAY COVER
REMOVAL/INSTALLATION ).

5. Remove the screws (A) and the mounting nuts (B) from the bracket. Cover the lid and dashboard with a

cloth, and pry carefully with a screwdriver to lift the front passenger's airbag (C) out of the dashboard.

NOTE:

The airbag lid has pawls (D) on its side that attach it to the dashboard.



2007 Honda Element EX

2007-08 RESTRAINTS SRS (Supplemental Restraint System) - Element



Fig. 253: Identifying Front Passenger's Airbag Screws And Mounting Nuts

INSTALLATION

1. Place the new front passenger's airbag (A) into the dashboard. Tighten the mounting nuts (B) and screws

(C).



2007 Honda Element EX

2007-08 RESTRAINTS SRS (Supplemental Restraint System) - Element



Fig. 254: Identifying Front Passenger's Airbag Mounting Nuts And Screws

2. Reinstall the dashboard tray cover and the passenger's dashboard upper panel (see PASSENGER'S

DASHBOARD UPPER PANEL AND DASHBOARD TRAY COVER
REMOVAL/INSTALLATION ).

3. Connect the front passenger's airbag 4P connector (A) to the dashboard wire harness.

Fig. 255: Identifying Front Passenger's Airbag 4P Connector

4. Reinstall the glove box (see GLOVE BOX REMOVAL/INSTALLATION ).

5. Reconnect the negative cable to the battery.

6. After installing the airbag, confirm proper system operation: Turn the ignition switch ON (II); the SRS

indicator should come on for about 6 seconds and then go off.

SIDE AIRBAG REPLACEMENT

NOTE:

Review the seat replacement procedure before doing repairs or service (see



2007 Honda Element EX

2007-08 RESTRAINTS SRS (Supplemental Restraint System) - Element



REMOVAL

1. Disconnect the negative cable from the battery, and wait at least 3 minutes before beginning work.

2. Disconnect the side airbag harness 2P connector (A).

Fig. 256: Identifying Side Airbag Harness 2P Connector

3. Remove the seat assembly (see FRONT SEAT REMOVAL/INSTALLATION ) and seat-back cover

(see FRONT SEAT-BACK COVER REPLACEMENT ).

4. Remove the mounting nuts (A), then remove the side airbag (6).

Fig. 257: Identifying Side Airbag Mounting Nuts

INSTALLATION

FRONT SEAT REMOVAL/INSTALLATION ).

NOTE:



If the side airbag lid is secured by tape, remove the tape.



Do not open the lid of the side airbag cover.



Use new mounting nuts tightened to the specified torque. When you



2007 Honda Element EX

2007-08 RESTRAINTS SRS (Supplemental Restraint System) - Element
