Fig. 73: Measuring Resistance Between SRS Unit Connector B (28P) Terminal 1 And 2 Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (28P) and the SRS unit. Check the NO -Short in the floor wire harness; replace the floor wire harness. DTC 21-8X ("X" CAN BE 0 THRU 9 OR A THRU F): SHORT TO POWER IN DRIVER'S SEAT BELT Special Tools Required SRS inflator simulator 07SAZ-TB4011A SRS simulator lead K 070AZ-SNAA200 1. Clear the DTC memory (see CLEAR THE DTC MEMORY WITH THE HDS ). 2. Turn the ignition switch ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator stay on, and is DTC 21-8x indicated? YES -Go to step 3. NO -Intermittent failure, system is OK at this time. Go to Troubleshooting Intermittent Failures (see 3. Turn the ignition switch OFF. Disconnect the negative cable from the battery, and wait for 3 minutes. NOTE: Before doing this troubleshooting procedure, review SRS Precautions and
2007 Honda Element EX 2007-08 RESTRAINTS SRS (Supplemental Restraint System) - Element
|
