Honda Element. Manual - part 81
MONITOR DESCRIPTION
Enable Conditions
ENABLE CONDITIONS
Malfunction Threshold
The difference between the BARO sensor output and the MAP sensor output is 28 kPa (8.1 in.Hg, 204 mmHg)
or more for at least 2.5 seconds.
Driving Pattern
1. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator
fan comes on.
2. Drive the vehicle with the throttle position as specified under Enable Conditions for at least 2.5 seconds.
Drive the vehicle in this manner only if the traffic regulations and ambient conditions allow.
Diagnosis Details
Conditions for illuminating the MIL
When a malfunction is detected during the first drive cycle, a Temporary DTC is stored in the ECM/PCM
memory. If the malfunction recurs during the next (second) drive cycle, the MIL comes on and the DTC and the
freeze frame data are stored.
Conditions for clearing the MIL
The MIL will be cleared if the malfunction does not recur during three consecutive trips in which the diagnostic
runs.
Execution
Once per driving cycle
Sequence
None
Duration
2.5 seconds or more
DTC Type
Two drive cycles, MIL ON
OBD Status
PASSED/FAILED/NOT COMPLETED (STILL TESTING)
Condition
Minimum
Maximum
Throttle
position
1,000
rpm
13.0 °
-
3,000
rpm
28.0 °
No active DTCs
P0107, P0108, P0117, P0118, P0122, P0123, P0171, P0172, P0222, P0223, P0300,
P0301, P0302, P0303, P0304, P0341, P0506, P0507, P1128, P1129, P2101, P2108,
P2118, P2122, P2123, P2127, P2128, P2135, P2138, P2176, P2228, P2229, P2646,
P2647, P2648, P2649, U0107
