Fig. 122: Shift Solenoid Valve Output (D Position) Hydraulic Pressure Supply To Clutch By Shift General Description Hydraulic pressure to each clutch is controlled by the shift valve. The shift valve activates according to the Monitor Execution, Sequence, Duration, DTC Type, OBD Status MONITOR DESCRIPTION Enable Conditions ENABLE CONDITIONS Execution Continuous Sequence None Duration 2.5 seconds DTC Type Two drive cycles, MIL ON, D indicator blinks OBD Status PASSED/FAILED/NOT COMPLETED (STILL TESTING) Condition Minimum Maximum Battery 11.0 V - ATF (1) , (3) - Throttle 4.0 % or more, or fully closed (1) , (3) 6.0 % or more, or fully closed (2)
2007 Honda Element EX 2007 ENGINE PERFORMANCE Advanced Diagnostics - Element
|
