Honda Civic. Manual - part 993





Fig. 5: Maintenance Reminder Light Reset
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2000-05 INSIGHT

1. When distance driven since maintenance required indicator was reset is 6000

miles, the MAINT REQ'D reminder light will start to blink. After exceeding
7500 miles without having scheduled maintenance performed and MAINT
REQ'D reminder light reset, light will remain on until it is reset.

2. To reset the light, turn ignition switch to OFF position. Press and hold TRIP

button, located on lower right side of instrument cluster. While still holding
TRIP button, turn ignition switch to ON position with engine off. Hold button
for about 10 seconds until indicator resets.



2008 Honda Civic EX

GENERAL INFORMATION Service Reminder Indicators - Honda

































2000-05 S2000

1. For the first 8000 miles after maintenance required indicator is reset, the

MAINT REQ'D reminder light illuminates when the ignition is turned on, then
will go out after 2 seconds. Between 8000-10,000 miles, the MAINT REQ'D
reminder light will light for 2 seconds, then will flash for 10 seconds, and will
then go out. After exceeding 10,000 miles without having scheduled
maintenance performed, MAINT REQ'D reminder light will remain on until it
is reset.

2. To reset the MAINT REQ'D reminder light, turn ignition switch to OFF

position. Press and hold the trip meter reset button while turning ignition
switch to ON position, with engine off. Hold button until indicator resets
(indicator light goes out).

2001-05 CIVIC

1. For the first 8000 miles after maintenance required indicator is reset, the

MAINT REQ'D indicator light illuminates when the ignition is turned on, then
will go out after 2 seconds. When mileage is 8000-10,000 miles, the MAINT
REQ'D reminder light will illuminate for 2 seconds, then blink for 10 seconds,
and then go out. When mileage exceeds 10,000 miles, MAINT REQ'D
indicator light illuminates and stays on while ignition switch is in ON (II)
position.

2. To reset the MAINT REQ'D indicator light, turn ignition switch to OFF

position. Press and hold the SELECT/RESET button. While still holding
button, turn ignition switch to ON position, with engine off. Hold
SELECT/RESET button for about 10 seconds until indicator resets.

3. If MAINT REQ'D reminder light does not reset, ensure headlights, parking

lights, or both are turned off when resetting reminder light. The MAINT
REQ'D indicator can not be reset if any of these lights are on. If vehicle is
equipped with daytime running lights and lights come on when ignition switch
is turned to ON (II) position, daytime running lights must be disabled before
indicator light can be reset.

2002-05 CR-V

1. For the first 8000 miles after maintenance required indicator is reset, the



2008 Honda Civic EX

GENERAL INFORMATION Service Reminder Indicators - Honda

































MAINT REQ'D reminder light illuminates when the ignition is turned on, then
will go out after 2 seconds. When mileage is 8000-10,000 miles, the MAINT
REQ'D reminder light will illuminate for 2 seconds, then blink for 10 seconds,
and will then go out. When mileage exceeds 10,000 miles, MAINT REQ'D
light illuminates and stays on while ignition switch is in ON (II) position.

2. To reset the light, turn ignition switch to OFF position. Press and hold the

SELECT/RESET button. While still holding button, turn ignition switch to ON
position, with engine off. Hold SELECT/RESET button for about 10 seconds
until indicator resets.

2003-05 ACCORD (4-CYLINDER)

1. When distance driven since maintenance required indicator was reset is less

than 8000 miles, the MAINT REQ'D reminder light will illuminate for 2
seconds and then go out when ignition switch is turned to ON (II) position.
When mileage is 8000-10,000 miles, MAINT REQ'D indicator light will
illuminate for 2 seconds and then blink for 10 seconds when ignition switch is
turned to ON (II) position. When mileage exceeds 10,000 miles, MAINT
REQ'D light illuminates and stays on while ignition switch is in ON (II)
position.

2. To reset MAINT REQ'D indicator light, turn ignition switch to OFF position.

Push and hold the SELECT/RESET button and turn ignition switch to ON (II)
position. Continue to hold button for more than 10 seconds or until MAINT
REQ'D light goes out.

2003-05 ACCORD (V6)

1. When distance driven since maintenance required indicator was reset is less

than 6000 miles, the MAINT REQ'D reminder light will illuminate for 2
seconds and then go out when ignition switch is turned to ON (II) position.
When mileage is 6000-7500 miles, MAINT REQ'D indicator light will
illuminate for 2 seconds and then blink for 10 seconds when ignition switch is
turned to ON (II) position. When mileage exceeds 7500 miles, MAINT REQ'D
light illuminates and stays on while ignition switch is in ON (II) position.

2. To reset MAINT REQ'D indicator light, turn ignition switch to OFF position.

Push and hold the SELECT/RESET button and turn ignition switch to ON (II)



2008 Honda Civic EX

GENERAL INFORMATION Service Reminder Indicators - Honda



































position. Continue to hold button for more than 10 seconds or until MAINT
REQ'D light goes out.

2003-05 ELEMENT

1. For the first 8000 miles after maintenance required indicator is reset, the

MAINT REQ'D indicator light illuminates when the ignition is turned on, then
will go out after 2 seconds. When mileage is 8000-10,000 miles, the MAINT
REQ'D reminder light will illuminate for 2 seconds, then blink for 10 seconds,
and then go out. When mileage exceeds 10,000 miles, MAINT REQ'D
indicator light illuminates and stays on while ignition switch is in ON (II)
position.

2. To reset the MAINT REQ'D indicator light, turn ignition switch to OFF

position. Press and hold the SELECT/RESET button. While still holding
button, turn ignition switch to ON position, with engine off. Hold
SELECT/RESET button for about 10 seconds until indicator resets.

3. If MAINT REQ'D reminder light does not reset, ensure headlights, parking

lights, or both are turned off when resetting reminder light. The MAINT
REQ'D indicator can not be reset if any of these lights are on. If vehicle is
equipped with daytime running lights and lights come on when ignition switch
is turned to ON (II) position, daytime running lights must be disabled before
indicator light can be reset.

2003 PILOT

1. For the first 6000 miles after maintenance required indicator is reset, the

MAINT REQ'D reminder light illuminates when the ignition is turned on, then
will go out after 2 seconds. When mileage is 6000-7500 miles, the MAINT
REQ'D reminder light will illuminate for 2 seconds, then blink for 10 seconds,
and will then go out. When mileage exceeds 7500 miles, MAINT REQ'D light
illuminates and stays on while ignition switch is in ON (II) position.

2. To reset the light, turn ignition switch to OFF position. Press and hold the

SELECT/RESET button. While still holding button, turn ignition switch to ON
position, with engine off. Hold SELECT/RESET button for about 10 seconds
until indicator resets.

2004 ODYSSEY



2008 Honda Civic EX

GENERAL INFORMATION Service Reminder Indicators - Honda
