Fig. 8: Removing Deflector Bases, Hooks And Springs

5. Install the deflector in the reverse order of removal.
6. Reset the moonroof control unit (see RESETTING THE MOONROOF

CONTROL UNIT ).

DRAIN CHANNEL REPLACEMENT

1. Remove the glass (see GLASS REPLACEMENT ).
2. With the moonroof wrench, move both glass brackets (A) to the position where

the moonroof normally tilts up and disconnect the drain channel rods (B) on
both sides.

2008 Honda Civic EX

2006-08 ACCESSORIES & EQUIPMENT Moonroof - Civic

Fig. 9: Moving Both Glass Bracket To Position Tilts Up

3. Slide the drain channel (A) forward.

Fig. 10: Sliding Drain Channel Forward

4. Pull the rear edge of the drain channel (A) up while pushing both clips (B), and

release the channel from both hooks (C) of the drain channel slider by pulling
it rearward.

2008 Honda Civic EX

2006-08 ACCESSORIES & EQUIPMENT Moonroof - Civic

Fig. 11: Releasing Channel From Hooks Of Drain Channel Slider

5. Remove the drain channel.
6. Install the channel in the reverse order of removal, and note these items:

Push the clip portions into place securely.

Check the glass position adjustment (see GLASS POSITION
ADJUSTMENT ).

7. Check for water leaks. Let the water run freely from a hose without a nozzle.

Do not use a high-pressure spray.

SUNSHADE REPLACEMENT

1. Remove the drain channel (see DRAIN CHANNEL REPLACEMENT ).
2. Slide the sunshade (A) until you can see both sunshade slider spacers (B).

2008 Honda Civic EX

2006-08 ACCESSORIES & EQUIPMENT Moonroof - Civic

Fig. 12: Sliding Sunshade

3. Remove the screws, then remove both spacers.
4. While lifting the front portion of the sunshade (A), move the sunshade forward

until you can see both sunshade rear hooks (B). Do not damage the sunshade
and hooks.

Fig. 13: Moving Sunshade Forward
