1. Remove these items:

Rear seat cushion (see REAR SEAT CUSHION COVER
REPLACEMENT )

Rear seat-back:

- Fold down (see SEAT-BACK - FOLD DOWN - 4-DOOR )
- Split fold down (see SEAT-BACK - SPLIT FOLD DOWN - 4-
DOOR )

Rear seat side bolster, both sides (see SEAT SIDE BOLSTER - 4-
DOOR )

Rear door opening seal, as needed (see REAR DOOR SILL AREA - 4-
DOOR )

C-pillar trim, both sides (see C-PILLAR TRIM - 4-DOOR )

2. From the trunk compartment, disconnect the high mount brake light connector

(A).

Fig. 60: Disconnecting Mount Brake Light Connector

3. Except Si model: From the trunk compartment, release the white clips (A) by

tapping on them.

NOTE:

Put on gloves to protect your hands.

Take care not to bend or scratch the rear shelf and trim.

Use the appropriate tool from the KTC trim tool set to
avoid damage when prying components.

2008 Honda Civic EX

2006-08 ACCESSORIES & EQUIPMENT Interior Trim - Civic (All Except Hybrid)

Fig. 61: Releasing White Clips (Except Si Model)

4. Si model: From the trunk compartment, release the white clips (A) by tapping

on them.

2008 Honda Civic EX

2006-08 ACCESSORIES & EQUIPMENT Interior Trim - Civic (All Except Hybrid)

Fig. 62: Releasing White Clips (Si Model)

5. Release the hooks (A) by pushing in on the detents (B) on the rear shelf (C),

then lift up on the front edge of the shelf at each detent.

2008 Honda Civic EX

2006-08 ACCESSORIES & EQUIPMENT Interior Trim - Civic (All Except Hybrid)

Fig. 63: Releasing Hooks Pushing In On Detents On Rear Shelf

6. Lift the rear shelf (A) upward to detach the remaining four clips. Except Si

model: Release the hooks (B) of the high mount brake light from the rear shelf.
Release the pin (C) from the holes on the body.

2008 Honda Civic EX

2006-08 ACCESSORIES & EQUIPMENT Interior Trim - Civic (All Except Hybrid)
