Fig. 41: Installing Clip To Quarter Pillar Trim
15. Reinstall the quarter pillar trim (A).
-1 Fit the upper edge of the trim to the headliner (B).
-2 Place the trim over the center/C-pillar (C), and fit its B-pillar upper clip
(D), C-pillar upper clip (E), and all of the other clips (F, G) into holes (H)
in the body, then lightly push the trim into place.
NOTE:
Make sure the side curtain airbag isn't tucked
down under the clips and ribs.
Apply pressure to the areas of the trim just
upon the quarter/C-pillar upper clips until these
clip fittings are felt. If you push too hard, the
clip will be damaged, and it will not hold the
trim properly.
Make sure the upper clip portions of the trim
don't come off the body by tugging on the trim
