1. Remove these items: Front door sill trim (see FRONT DOOR SILL AREA - 4-DOOR ) Rear door sill trim (see REAR DOOR SILL AREA - 4-DOOR ) Front door opening seal, as needed (see step 4 in FRONT DOOR SILL Rear door opening seal, as needed (see step 3 in REAR DOOR SILL 2. Slide the front seat forward fully. -1 Pull the upper portion of the trim back to release the upper hooks (B). Fig. 26: Removing B-Pillar Lower Trim 4. Remove the front seat belt lower anchor (see FRONT SEAT BELT REPLACEMENT ). 5. Pull the bottom of the B-pillar upper trim (A) back by hand to detach the lower hooks (B). Use the appropriate tool from the KTC trim tool set to
2008 Honda Civic EX 2006-08 ACCESSORIES & EQUIPMENT Interior Trim - Civic (All Except Hybrid)
|
