6. If the side curtain airbag has not deployed, remove the upper clip (A) from the removed A-pillar trim (B) and discard it. Then check the trim: To prevent the side curtain airbags from deploying improperly and -Any cracks, deformations, or stress-whitening in the A-pillar trim Replace the lower clips (E) if it is damaged. Replace the upper clip with a new one. 4-door A-pillar trim is shown; 2-door A-pillar trim is similar. Fig. 21: Removing Upper Clip From A-Pillar Trim 7. Before installing the A-pillar trim (A), whether replaced or reinstalled, temporarily remove a new upper clip (B).
2008 Honda Civic EX 2006-08 ACCESSORIES & EQUIPMENT Interior Trim - Civic (All Except Hybrid)
|
