3. Replace the plug at the specified interval, or if the center electrode is rounded (A), or if the spark plug gap is out of specification. Use only the listed spark Spark Plugs NGK: IZFR6K11S DENSO: SKJ20DR-M11S Electrode Gap Standard (New): 1.0-1.1 mm (0.039-0.043 in.) Fig. 12: Identifying Spark Plugs And Electrode Gap 4. Apply small amount of anti-seize compound to the plug threads, and screw the plugs into the cylinder head, finger-tight. Then torque them to 25 N.m (2.5 electrode since this will damage the electrode. When using a sand blaster spark plug cleaner, do NOTE: Do not adjust the gap (B) of iridium tip plugs.
2008 Honda Civic EX 2006-08 ENGINE Ignition System (R18A1) - Civic (All Except Hybrid)
|
