Fig. 40: Identifying Dials And Heater Control Panel 3. Install the control panel in the reverse order of removal. After installation, operate the various functions to make sure they work properly. 4. Run the self-diagnosis function to confirm that there are no problems in the system (see HOW TO USE THE SELF-DIAGNOSTIC FUNCTION ). DUST AND POLLEN FILTER REPLACEMENT 1. Open the glove box. Remove the glove box stop on each side, then let the glove box hang down (see PASSENGER'S DASHBOARD UNDERCOVER 2. Remove the dust and pollen filter assembly (A) from the evaporator. Fig. 41: Identifying Dust And Pollen Filter Assembly 3. Remove the filter (A) from the housing (B), and replace the filter.
2008 Honda Civic EX 2006-08 HVAC Heating - Civic (All Except Hybrid)
|
