14. Attach the fasteners (A) with adhesive tape to the rear window opening flange of the body on both sides. Fasteners adhesive tape: Thickness 0.8 mm (0.031 in.) Fig. 48: Attaching Fasteners With Adhesive Tape To Rear Window 15. Set the rear window in the opening, and center it. Make alignment marks (A) across the rear window and body with a grease pencil at the four points shown. Make sure both pins (C) from the upper fasteners (D) contact with the edge of
2008 Honda Civic EX 2006-08 ACCESSORIES & EQUIPMENT Glass - Civic (All Except Hybrid)
|
