Fig. 33: Applying Primer To Edge Of Rear Window (With Specifications) 15. Attach the upper rubber dams (A), side rubber dam (B), clips (C), and fasteners (D) with adhesive tape to the inside face of the rear window (E) as shown in First attach the upper rubber dam, then attach the side rubber dams around Be sure the clips, and fasteners line up with the alignment marks (F). Be careful not to touch the rear window where adhesive will be applied. Rubber dams adhesive tape: Thickness 0.16 mm (0.006 in.)
2008 Honda Civic EX 2006-08 ACCESSORIES & EQUIPMENT Glass - Civic (All Except Hybrid)
|
