Honda Civic. Manual - part 622

Fig. 40: Disconnecting FTP Sensor Connector
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Disconnect the hose (B), and remove the FTP sensor (C).
4. Install the sensor in the reverse order of removal with a new O-ring (D) and a

new retainer (E).

EVAP CANISTER VENT SHUT VALVE REPLACEMENT

1. Remove the EVAP canister (see EVAP CANISTER REPLACEMENT ).
2. Remove the cap (A).

2008 Honda Civic EX

2006-08 ENGINE PERFORMANCE EVAP System (R18A1) - Civic (All Except Hybrid)

Fig. 41: Removing Cap
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Remove the EVAP canister vent shut valve (B).
4. Install the parts in the reverse order of removal with new O-rings (C) and a

new cap.

EVAP CANISTER PURGE VALVE REPLACEMENT

1. Remove the cowl cover and under-cowl panel (see COWL COVER

REPLACEMENT ).

2. Disconnect the hose (A) and the EVAP canister purge valve 2P connector (B).

Fig. 42: Disconnecting Hose And EVAP Canister Purge Valve 2P
Connector (With Specifications)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

3. Remove the EVAP canister purge valve (C).
4. Install the parts in the reverse order of removal with a new O-ring (D).

NOTE:

Do not coat the O-rings with oil.

2008 Honda Civic EX

2006-08 ENGINE PERFORMANCE EVAP System (R18A1) - Civic (All Except Hybrid)

2006-08 ACCESSORIES & EQUIPMENT

Exterior Lights - Civic (All Except Hybrid)

COMPONENT LOCATION INDEX

4-door except Si model

Fig. 1: Locating Exterior Lights Components (4-Door Except Si Model - 1 Of

2008 Honda Civic LX

2006-08 ACCESSORIES & EQUIPMENT Exterior Lights - Civic (All Except Hybrid)

2008 Honda Civic LX

2006-08 ACCESSORIES & EQUIPMENT Exterior Lights - Civic (All Except Hybrid)

2)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

Fig. 2: Locating Exterior Lights Components (4-Door Except Si Model - 2 Of
2)
Courtesy of AMERICAN HONDA MOTOR CO., INC.

2-door except Si model

2008 Honda Civic LX

2006-08 ACCESSORIES & EQUIPMENT Exterior Lights - Civic (All Except Hybrid)
