0.5-1.0 g (0.02-0.04 oz) 6-speed M/T model (Si): 2.0-3.0 g (0.08-0.12 oz) Fig. 51: Identifying Area Applying Grease 4. Clean the areas where the driveshaft contacts the differential thoroughly with solvent or brake cleaner, and dry with compressed air. 5. Insert the inboard end (A) of the driveshaft into the differential (B) or intermediate shaft (C) (M/T model) until the set ring (D) locks in the groove NOTE: Do not wash the rubber parts with solvent. NOTE: Insert the driveshaft horizontally to prevent damaging
2008 Honda Civic GX 2006-08 DRIVELINE/AXLES Driveline/Axle - Civic (All Except Hybrid)
|
