Fig. 19: Clamping Driveshaft In Bench Vise 6. Remove the outboard joint (A) using the threaded adapter (B) and a commercially available 5/8"-18 UNF slide hammer (C). 7. Remove the driveshaft from the bench vise. Fig. 20: Identifying Stop Ring 9. Wrap the splines on the driveshaft with vinyl tape (A) to prevent damaging to the boot.
2008 Honda Civic GX 2006-08 DRIVELINE/AXLES Driveline/Axle - Civic (All Except Hybrid)
|
