Fig. 53: Releasing Hooks Prying Out Rear Portion Of Inner Handle Cap 3. Remove the screw (A) and clip (B) securing the inner handle (C). Fig. 54: Removing Inner Handle Screw And Clip 4. Remove the power window switch panel (A). 1 Using the appropriate trim tool, pry up on the rear edge of the switch 2 Pull out along the edge of the panel to release the hooks (B). 3 Pull the switch panel rearward to release the front hook (C). 4 Disconnect the power window switch connector (D).
2008 Honda Civic LX 2006-08 ACCESSORIES & EQUIPMENT Doors - Civic (All Except Hybrid)
|
