Fig. 11: Removing Door Panel Screws 7. Remove the door panel (A) with as little bending as possible to avoid creasing or breaking it. 1 Start at the bottom edge of the door panel, release the clips (B, C) with a 2 Detach the upper clips. 3 Starting at the rear, pull the door panel upward. 4 Disconnect the power window switch connector (D). NOTE: The inner handle cable (E) and latch cable (F) are
2008 Honda Civic LX 2006-08 ACCESSORIES & EQUIPMENT Doors - Civic (All Except Hybrid)
|
