Honda Civic. Manual - part 405





Fig. 26: Identifying Air Cleaner Housing Bracket (With Torque
Specifications)


20. Install the harness clamps (A), and remove the positive crankcase ventilation

(PCV) hose from the clamp (B).

Fig. 27: Identifying Positive Crankcase Ventilation (PCV) Hose Clamp

21. Install the intake manifold (see INSTALLATION ).
22. Install the drive belt, refer to the DRIVE BELT

REMOVAL/INSTALLATION .

23. Clean the battery posts and cable terminals with sandpaper. Assemble them,



2008 Honda Civic GX

2006-08 ENGINE Cylinder Head - Civic GX



































and apply grease to prevent corrosion.

24. After installation, check that all tubes, hoses and connectors are installed

correctly.

25. Do the leak Inspection (see LEAK INSPECTION ).
26. Refill the radiator with engine coolant, and bleed air from the cooling system

with the heater valve open, refer to the step 8 on COOLANT
REPLACEMENT
 .

27. Do the crankshaft position (CKP) pattern clear/CKP pattern learn procedure

(see CRANK (CKP) PATTERN CLEAR/CRANK (CKP) PATTERN
LEARN
 ).

28. Do the power window control unit reset procedure, refer to the RESETTING

THE POWER WINDOW CONTROL UNIT .

29. Inspect the idle speed, refer to the IDLE SPEED INSPECTION .
30. Inspect the ignition timing, refer to the IGNITION TIMING INSPECTION .
31. Enter the anti-theft codes for the audio system and navigation system (if

equipped).

32. Set the clock.



2008 Honda Civic GX

2006-08 ENGINE Cylinder Head - Civic GX



































2006-08 ACCESSORIES & EQUIPMENT

Dashboard - Civic (All Except Hybrid)

INSTRUMENT PANEL REMOVAL/INSTALLATION

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-
424-6857

1. Remove these items:



Subdisplay visor (see SUBDISPLAY VISOR
REMOVAL/INSTALLATION
 )



Navigation unit, with navigation system (see NAVIGATION UNIT
REMOVAL/INSTALLATION
 )



Audio unit, without navigation system (see AUDIO UNIT
REMOVAL/INSTALLATION
 )

2. Remove the screws.

NOTE:



Take care not to scratch the dashboard and related
parts.



Use the appropriate tool from the KTC trim tool set to
avoid damage when prying components.



2008 Honda Civic EX

2006-08 ACCESSORIES & EQUIPMENT Dashboard - Civic (All Except Hybrid)





2008 Honda Civic EX

2006-08 ACCESSORIES & EQUIPMENT Dashboard - Civic (All Except Hybrid)































































Fig. 1: Removing Instrument Panel Screws

3. Detach the clips along the lower edge of the instrument panel (A).

Fig. 2: Detaching Clips Along Lower Edge Of Instrument Panel

4. Detach the clips along the upper edge of the instrument panel (A). Gently pull

out the instrument panel to release the hooks (B) from the holder (C) of the
gauge control module.



2008 Honda Civic EX

2006-08 ACCESSORIES & EQUIPMENT Dashboard - Civic (All Except Hybrid)
