12. Lift up the rear of the console (A), and remove it from the dashboard. Fig. 10: Removing Rear Of Console 13. Install the console in the reverse order of removal, and note these items: Make sure each connector is plugged in properly. Check if the clips are damaged or stress-whitened, and if necessary, Push the clips and hooks into place securely. When installing the center console panel, install the tabs (A) into the notch Fig. 11: Installing Console 14. Si model: Install the shift knob (A). 1 By hand, thread the locknut (B) on to the shaft unit it bottoms out on the
2008 Honda Civic EX 2006-08 ACCESSORIES & EQUIPMENT Consoles - Civic (All Except Hybrid)
|
