Fig. 74: Removing Center Pivot Bracket (With Specifications) 3. If necessary, remove the bushing (B). 1 Fold the left seat-back forward. 2 Pull the rear center seat belt (B) out through the slit (C) in the seat belt 3 Release the velcro fastener (E), and pull back the seat-back cover (F), 4 Release the hooks (G) of the pivot bracket (H).
2008 Honda Civic EX 2006-08 ACCESSORIES & EQUIPMENT Seats - Civic (Except Hybrid)
|
