Fig. 11: Identifying Ring Pliers And Clips REAR SEAT CUSHION COVER REPLACEMENT 1. Remove the seat cushion (see REAR SEAT REMOVAL/INSTALLATION ). 2. From the back of the seat-back, pass both lower retainers (A) through the slots in the seat cushion pad, and release all the clips (B), and fold back the seat Fig. 12: Removing Seat Cushion NOTE: Put on gloves to protect your hands. Take care not to tear the seams or damage the seat
2008 Honda Civic EX 2006-08 ACCESSORIES AND EQUIPMENT Seats - Civic GX
|
