137. Driver’s Door (Sedan)

DOOR MULTIPLEX
CONTROL UNIT

CONNECTOR A
(20-BLU)

CONNECTOR B
(2-BRN)

POWER MIRROR
SWITCH

138. Rear of Driver’s Door Panel (EX)

SECURITY INDICATOR
CONNECTOR (2-GRY)

139. Driver’s Door (Frt. Pass. Similar)

LEFT POWER
MIRROR
CONNECTOR
(Right Similar)
(3-GRY) (USA)
(6-CAVITY)
(Canada)

DOOR LOCK
SWITCH
CONNECTOR
(3-GRY)

140. Driver’s Door (Frt. Pass. Similar) (Sedan)

WINDOW
MOTOR
(Behind)

WINDOW MOTOR
CONNECTOR
(4-GRY) (DRIVER’S)
(2-GRY) (FRT. PASS.)

DOOR
SPEAKER
