Honda Accord Electrical Troubleshooting Manual - part 1

 2002 American Honda Motor Co., Inc.

Connector Views

Male
Terminal

Cavity/
Terminal 6

The cavities (and wire terminals) in each connector are numbered starting from the upper left, looking
at the male terminals from the terminal side (or looking at the female terminals from the wire side. Both
views are in the same direction so the numbers are the same.) All actual cavities are numbered, even if
they have no wire terminals in them.

Female
Terminal

The connector cavity number is listed next to each terminal on the circuit schematic.
The cavity/terminal shown below is #6.

Wire Side

of

Female Terminals

Terminal Side

of

Male Terminals

1

2

3

4

5

6

6

C103

Terminal Numbering System

Circuit Index

Circuit Index

Menu

Menu

s

t

s

t

6

Driver’s Under-dash Fuse/Relay Box

Fuse-to-Components Index

11
10

9

8
7

6

5
4

3

2

1

13

12

Fuse

Number

Fuse Name

Amps

Page

Component or Circuit Protected

1

FUEL PUMP

15

10-4

PGM-FI main relay, SRS unit (VA)

2

SRS

10

10-4

SRS unit (VB)

3

HEATER CONTROL
A/C CLUTCH RELAY
COOLING FAN RELAY

7.5

10-5

A/C compressor controls, Air delivery, Blower
controls, Fans, Rear window defogger relay, Seat
heaters (Canada EX)

4

R/C MIRROR

7.5

10-4

ABS control unit (All except ’01-’02 V6), ABS/TCS
control unit (’01-’02 V6), Power mirrors, Power mirror
defoggers (Canada), Option connector S

5

(DAY LIGHT)

7.5

10-4

DRL control unit (Canada)

6

ECU
CRUISE CONTROL

15

10-6 (L4)

or

10-7 (V6)

Charging system, Cruise control, Engine mount
control system, Evaporative emission control system,
Fuel and emissions, Gauge assembly, Radiator fan
control module (V6), VSS (M/T)

7

FR WASHER
(SUN ROOF RELAY)
(SIDE SRS) (SRS)

7.5

10-8

Wiper/washer, SRS (with side SRS)

8

ACC RELAY

7.5

10-8

Accessory power socket relay, Option connector R

9

BACK UP LIGHT
INSTRUMENT LIGHT

7.5

10-9

Back-up lights, Brake light failure sensor, Clock,
Driver’s and passenger’s multiplex control units, DRL
indicator (Canada), Gauge assembly, Security
system (USA except EX), Shift lock solenoid (A/T)

10

TURN LIGHTS

7.5

10-8

Turn signal/hazard relay

11

IG COIL

15

10-8

Ignition coil (L4)

12

FR WIPER

30

10-8

Wiper/washer

13

STARTER SIGNAL

7.5

10-3

PCM or ECM, PGM-FI main relay, Starter

E

Circuit Index

Circuit Index

Menu

Menu

▲

▼

▲

▼

+

–

6-1

Driver’s Under-dash Fuse/Relay Box

Connector-to-Fuse/Relay Box Index

3

7

12

11
10

9

8
7

6

5
4

3

2

1

13

12

11

10

9

21

5

4

2

1

22

23

24

25

26

27

28

18

17

16

15

14

13

8

6

20

19

Front View

Rear View

Ref

Socket

Cavities

Connects to

1

In-line diode 2

—

Circuit 174

(see page 15-5)

2

In-line diode 1

—

Circuit 173

(see page 15-5)

3

B

14

Left side wire harness

4

E

20

Left engine compartment wire harness

5

H

6

Not used

6

Multiplex control unit connector A

24

(Plugs directly into the fuse box)

7

Multiplex control unit connector B

22

Dashboard wire harness A

(see page 203-18)

8

D

—

Not used

9

G

18

Driver’s door wire harness

10

F

6

Driver’s door wire harness (Canada only)

11

C

5

Left engine compartment wire harness

12

A

10

Left side wire harness

13

J

3

Multiplex control inspection connector

14

I

18

Dashboard wire harness A

15

K

18

Dashboard wire harness A

16

M

6

Ignition switch lead

17

P

7

Dashboard wire harness B

18

Q

22

Dashboard wire harness B

19

Starter cut relay

4

20

Reverse relay

4

21

Turn signal/hazard relay

4

22

O

20

Dashboard wire harness B

23

N

2

SRS wire harness

24

L

—

Not used

25

T

1

Optional connector (B+: Fuse 42)

26

U

1

Optional connector (Dash lights: Circuit 11)

27

R

1

Optional connector (ACC: Fuse 8 – Driver’s)

28

S

1

Optional connector (IG2: Fuse 4 – Driver’s)

E

Circuit Index

Circuit Index

Menu

Menu

s

t

s

t

6-2

Passenger’s Under-dash Fuse/Relay Box

Fuse-to-Components Index

8

7

6

5

4

3

2

1

16

15

14

13

12

11

10

9

Fuse

Number

Fuse Name

Amps

Page

Component or Circuit Protected

1

(SUN ROOF MOTOR)

30

10-10

Moonroof

2

(POWER SEAT REC)

20

10-10

Power seat up-down motor (2-way adjustable),
Power seat rear up-down and recline motors (8-way
adjustable)

3

(POWER SEAT SLIDE)

20

10-10

Power seat slide motor (4-way adjustable)

4

(POWER SEAT SLIDE)

20

10-10

Power seat front up-down and slide motors (8-way
adjustable)

5

(POWER SEAT REC)

20

10-10

Power seat recline motor (4-way adjustable)

6

DAY LIGHT (Canada)
or
(LAF HEATER) (ULEV)

10

(Canada)

20

(ULEV)

10-10

DRL control unit (Canada), Primary HO2S relay
(ULEV)

7

(P/W REAR L) (COUPE)
(SUNROOF RELAY)
(SEDAN)

20

10-13

Left rear window motor, Moonroof open and close
relays

8

(P/W FRONT R)

20

10-13

Front passenger’s window motor

9

RADIO
CIGARETTE LIGHTER

20

10-10

Accessory power socket, Audio unit

E

Circuit Index

Circuit Index

Menu

Menu

s

t

s
