Dongfeng DFA1101GZ5AD6J-907. Manual - part 1

DFA1101GZ5AD6J-907

Light Commercial Truck

Operation Manual

DONGFENG AUTOMOBILE CO., LTD.

2006, 05

Foreword

                                            1

Foreword

Thank you for purchasing the DFA1101GZ5AD6J-907 light











commercial truck that manufactured by DONGFENG AUTOMOBILE
CO., LTD of the People's Republic of China.

This manual contains necessary procedures and instructions for the

operation, inspection and maintenance for your DFA1101GZ5AD6J-907
truck.

This vehicle is equipped with the EQB140-20 DONGFENG Cum-

mins diesel engine which could reach the  European  II  displacement
standard.

To obtain the optimum performance from your new vehicle is the

common goal for all of us, and it depends largely on your care and
familiarity of the operation and maintenance of the vehicles. We
sincerely hope that you read this manual thoroughly, and make sure that
you are familiar with the operation and maintenance before you using
the new truck.

The manual is a part of your vehicle. Please keep it with your truck.

The information and figures in this manual are correct when publishing.
Due to continuous improvement on our vehicles, maybe there are some
instructions in the manual that does not accord with the actual vehicles.
Please inquire when you get some problem.

The Application Section of Testing Department, Commercial product

R&D Institute of DONGFENG AUTOMOBILE CO., LTD. is in charge of
compiling this manual. DFAC reserve the right to make changes at any
time without notice.

As for vehicle saling, maintaining or spare parts purchasing, please

consult with the local agency.

The manual uses the legal unit.

                                                 DONGFENG AUTOMOBILE CO., LTD.
                                                                                              2006. 05

Truck Nameplate

                                            1—1

Truck Nameplate

Truck Nameplate Position

Engine Nameplate Position

VIN Position

Table of Content



 1

Table of Content

Truck Nameplate ......................................................................1-1

Truck Nameplate Position ........................................................ 1-1
Engine Nameplate Position...................................................... 1-1
VIN Position ............................................................................... 1-1

Main Technical Specifications

............................................2-1

Main Technical Specifications and Structure Features ......... 2-1
Operational Data ....................................................................... 2-2
Engine Parameter...................................................................... 2-2
Chassis Type and Structure Parameter .................................  2-3

Construction and Operation

...............................................3-1

Arrangement of the Cab ..........................................................  3-1
Doors.......................................................................................... 3-2
Seats..........................................................................................  3-3
Instruments................................................................................ 3-4
Indicators ................................................................................... 3-6
Keys............................................................................................ 3-9
Key Switch ................................................................................. 3-9
Light Combination Switch...................................................... 3-10
Power Switch........................................................................... 3-13
Exhaust Brake Switch............................................................. 3-13
Air Horn and Electric Horn Shift Switch ............................... 3-14
Air Drier Switch ....................................................................... 3-14
Dome Lamp and Glove Box ................................................... 3-14
Cab Skylight ............................................................................ 3-15
Air Conditioning System ........................................................ 3-15
Levers, Steering Wheel and Accessories ............................. 3-16
Tilting Cab................................................................................ 3-21

Vehicle Starting

......................................................................4-1

Engine Starting.......................................................................... 4-1
Engine Starting (when the cab is tilted) .................................  4-2
