3. Counter the fastening nuts -2- and open carefully. Note Before re-installing the component, check the O-rings of the refrigerant lines for damage and replaced them if Remove line 4. Pull the line and the rubber sleeve out of the passage to the plenum panel over the wheel housing. Installing the condenser-fluid tank line Installing the condenser-fluid tank line Insert line 1. Push line into the plenum panel via the wheel housing and press rubber sleeve into place. Ensure that rubber sleeve is fitted correctly. Diagnostic system: reading out fault memory and activating systems Installing the condenser-fluid tank line 3609 |
