87 03 17 Draining and filling in refrigerant - as of MY
2005

- General warning notes
- Technical values
- Draining and filling in refrigerant

Tools

Designation

Type

Number

Explanation

Air-conditioning recycling unit

commercially available tool

General warning notes

Warning notes for handling refrigerant

ATTENTION

Danger of injury when working on air-conditioned vehicles!

→ Observe safety regulations for working on air-conditioned vehicles and dealing with refrigerant

R134a. → 80  Safety regulations for working on air-conditioned vehicles and dealing with
refrigerant R134a

→ Observe safety regulations for working with extraction and filling systems. → 80  Safety

regulations for extraction and filling systems

→ Observe instructions for repairing air-conditioning systems and storing spare parts. → 80

 Instructions for repairing air-conditioning systems and storing spare parts

Technical values

Servicing equipment

Air-conditioning recycling unit

 , → " Gr. 2.5; Handbuch Werkstatteinrichtung"

3535

Draining and filling in refrigerant

Assembly work involving the refrigerant system

Note

During all work on the air-conditioning system which necessitates opening the refrigerant system, the system
contents must first be disposed of correctly!
Dirt and moisture must be kept out of the air-conditioning system's pipe system!
Thorough cleanliness must be ensured during all work!
System components must never be cleaned on the inside with hot steam!
Use only nitrogen for cleaning purposes!
When replacing a component, all openings must be closed off with suitable plugs!

General assembly sequence

The charging valves are located in the radiator tank at the front right.

Protective caps on charging valves

1. Screw off the protective caps on the charging

valves.

Pay attention to sealing rings when disconnecting or connecting the hose connections!

Service connection
