Press lower locking tabs together and unclip cushion carrier -1- ( -Inset B-
).

6. Press cushion carrier -1- outward slightly close to the backrest release and remove

it.

Installing cushion carrier for front backrest

Installing cushion carrier for front backrest

Installing cushion carrier

1. Press cushion carrier -1- outward slightly in area of backrest release and position it on the backrest frame

-2-

 until the locking tabs engage at the top -Inset A- and bottom -Inset B- .

Diagnostic system: reading out fault memory and activating systems

 Installing cushion carrier for front backrest

3213

Fastening cushion carrier at the sides

2. Press cushion carrier -1- at the sides into the frame for the side airbag -2- until the locking tabs engage.

Securing cushion carrier

3. Tighten fastening screws -1, 2- .

Installing cushion carrier for front backrest

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Installing cushion carrier for front backrest

3214

Installation position of cushion carrier

Diagnostic system: reading out fault memory and activating systems

Installing cushion carrier for front backrest

3215

Installing cushion carrier

1. Press cushion carrier -1- outward slightly close to the backrest release and position it on the backrest

frame -2- until the locking tabs engage at the top -Inset A- and bottom -Inset B- .

Securing cushion carrier

2. Tighten fastening screws -1- .

Installing collar

3. Position collar -2- on the cushion carrier -1- and press in until it clicks into place.

Diagnostic system: reading out fault memory and activating systems

Installing cushion carrier for front backrest

3216
