Note

Only for USA/Canada version vehicles.

•

Note

Passenger's seat only.

•

Locking the plug connection of the AWS control module

1. Push electric connector -1- onto AWS control module until it is felt to engage.

Connecting electrical plug connection (power seat)

Installation Location:

Overview, removing and installing front seat

Diagnostic system: reading out fault memory and activating systems

Locking the electrical plug connection of the AWS control module

3141

Note

Only for vehicles with electrically adjustable seat

Locking plug connection for seat memory

1. Push in electrical plug connection -1- -arrow A- until the locking tab audibly engages -arrow B- .

Locking central plug

Installation Location:

Overview, removing and installing front seat

Diagnostic system: reading out fault memory and activating systems

Connecting electrical plug connection (power seat)

3142

Locking central plug

1. Join the plug connection -1- -arrow A- , press in plug connector locking device -2- on the side -arrow B-

.

Tightening seat screws at rear

Installation Location:

Overview, removing and installing front seat

DANGER

Loosen the safety-related threaded joint.

Danger of injury if front seat is not screwed down correctly.

•

→ Always replace fastening screws for the front seat after customer service and reworking.

→ It is not permissible to make alterations to the micro-encapsulated screws (e.g., use lubricant, loosen bolts,

and screw them down again).

Diagnostic system: reading out fault memory and activating systems

Locking central plug

3143

Tightening seat screws at rear

1. Tip seat forwards and position seat rails on the seat baseframe.

2. Screw left and right fastening screws -1- into seat bracket -2- and tighten to specified tightening torque →

Micro-encapsulated: 50 (37 ftlb.) Nm

 .

Tightening seat screws at the front

Installation Location:

Overview, removing and installing front seat

DANGER

Loosen the safety-related threaded joint.

Danger of injury if front seat is not screwed down correctly.

•

→ Always replace fastening screws for the front seat after customer service and reworking.

→ It is not permissible to make alterations to the micro-encapsulated screws (e.g., use lubricant, loosen bolts,

and screw them down again).

1.

Diagnostic system: reading out fault memory and activating systems

Tightening seat screws at rear

3144
