Porshe 911 (997). Manual - part 744





Removing seat rail cover

1. Insert a screwdriver -1- under the lugs and press upwards slightly -arrow A- .

2. Pull seat rail covers -2- on right and left seat rails off in forward

direction.

Undoing seat screws at front

Installation Location:

Overview, removing and installing front seat

Diagnostic system: reading out fault memory and activating systems

Removing seat rail cover

3133

Undoing seat screws at front

1. Move seat -1- to its rear limit position and undo the front fastening screws -2- from the right and left seat

rails -3- .

Undoing seat screws at rear

Installation Location:

Overview, removing and installing front seat

Undoing seat screws at rear

1. Move seat to its front limit position and undo the fastening screws -1- from the right and left seat rails -2- .

Releasing electrical wire

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Undoing seat screws at front

3134

Overview, removing and installing front seat

1. Disconnect battery. → 271000  Work instructions after disconnecting the battery

Releasing electrical wire

2. Tilt seat backwards.

3. Unclip wiring harness -1- .

Disconnecting central plug

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Releasing electrical wire

3135

Overview, removing and installing front seat

Disconnecting central plug

1. Release plug connector locking device -1- on the side -arrow A- and separate the plug connection -2-

-arrow B-

 .

Disconnecting electrical plug connection (power seat)

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Disconnecting central plug

3136
