Porshe 911 (997). Manual - part 709

- Preliminary work
- Removing front luggage compartment cover
- Installing front luggage compartment cover
- Subsequent work

Preliminary work

Preliminary work

Remove luggage compartment light. → 964019 21 Removing and installing luggage compartment light -
"Removing" section

Removing front luggage compartment cover

Removing luggage compartment cover

Loosen luggage compartment lining

1. Unscrew plastic nut -1- -arrow A- and loosen luggage-compartment lining on the left-hand side -2-

-arrow B-

 .

2993

Loosening luggage compartment cover

2. Unscrew fastening screws -1- from the luggage compartment cover

-2-

 .

Removing luggage compartment cover

3. Remove luggage compartment cover -1- to the

front.

Checking support

4. Check support -1- and replace if necessary.

Installing front luggage compartment cover

Diagnostic system: reading out fault memory and activating systems

Removing luggage compartment cover

2994

Installing luggage compartment cover

Installing luggage compartment cover

1. Position luggage compartment cover -1- in the luggage compartment.

Fastening luggage compartment cover

2. Screw down luggage compartment cover -2- using the fastening screws -1- .

Fastening luggage compartment lining

3. Run in luggage-compartment lining -2- -arrow A- and fasten with the plastic nut -1- -arrow B- .

4. Check to ensure that lid seal is installed correctly.

Diagnostic system: reading out fault memory and activating systems

Installing luggage compartment cover

2995

Subsequent work

Subsequent work

Install luggage compartment light. → 964019 23 Removing and installing luggage compartment light -
"Installing" section

997110, 997111, 997120, 997121, 997310, 997311, 997320, 997321

WARNUNG

Gefahr des Verlusts der Text-Bild-Zuordnung beim Ausdruck.

Aus technischen Gründen kann derzeit nicht ausgeschlossen werden, dass trotz
einwandfreier Darstellung auf dem Bildschirm beim Ausdruck der
Zusammenhang von Text und zugehörigem Bild verloren geht.

•

Wird der Fehler nicht bemerkt, besteht die Gefahr, daß Arbeiten nicht korrekt
durchgeführt werden und es dadurch zu Personen- und Sachschäden kommt.

•

→ Vergleichen Sie deshalb nach dem Druckvorgang unbedingt die Ausdrucke mit der
Bildschirmdarstellung. Korrigieren Sie die Ausdrucke im Fehlerfall so, daß der Inhalt der
Bildschirmdarstellung zutreffend wiedergegeben wird.

WARNING

Danger of losing text-figure correspondence when printing out.

For technical reasons, it can currently not be ruled out that the correspondence
between text and associated figure can be lost when it is printed out, even though
the display on the screen is correct.

•

If the fault is not noticed, there is the danger that work will not be performed
correctly which can cause injury and damage.

•

→ Therefore, always compare printouts with the screen display after printing them out. Correct
the printouts if they are faulty so that the content of the screen display matches that on the
printouts.
