Porshe 911 (997). Manual - part 652

Installation location for centre console cover

Unclipping cover for support frame

1. Move in with a plastic wedge -3- between cover for support frame -1- and frame -2- and unclip cover -1-

-arrow A-

 .

2. Shift gearshift lever to the rear (4th gear) and take out cover -1- toward the top -arrow B- .

3. Check clamp -4- , replace if necessary.

Removing frame

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing cover for support frame

2765

Installation location for centre console cover

Removing frame

1. Loosen fastening screws -1- and take out frame -2- upwards.

2. Check clamp, replace if

necessary.

Removing Tiptronic cover

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing frame

2766

Installation location for centre console cover

Unclipping Tiptronic cover

1. Put selector lever -1- in position "R".

2. Unclip cover -2- with a plastic wedge and pull upwards slightly.

Removing Tiptronic cover

3. Put selector lever -1- in position "D" and take out cover -2- toward the top.

Diagnostic system: reading out fault memory and activating systems

Removing Tiptronic cover

2767

Installing cover for centre console

Installing Tiptronic cover

Installation Location:

Installation location for centre console cover

Installing Tiptronic cover

Note

Make sure that the rotary slide is positioned correctly.

1. Put selector lever -1- in position "D" and move in cover -2- .

Diagnostic system: reading out fault memory and activating systems

 Installing cover for centre console

2768
