Porshe 911 (997). Manual - part 606





Item

Designation

Item

Designation

-H1-

Cleaning solution

-H5-

Cartridge, component A

-H2-

Primer

-H6-

Cartridge, component B

-H3-

Activator

-H7-

Mixing nozzle

-H4-

Swab

-H8-

Processing nozzle

Glass separating tool

Item

Designation

Source

Explanation

-A-

Glass separating tool vag 1474
b

→ "See Workshop Equipment Manual, Chapter
3.5"

Contains set
components
A1-A9

-B-

Cutting thread

→ "See Parts Catalogue in Main Group 8"

Removing rear window

Removing rear window

Note

Diagnostic system: reading out fault memory and activating systems

Tools and materials

2581

The door windows must not be closed until after the curing time has elapsed.

•

1. Lower the door windows.

2. Pull off the plug for the rear window heater on the rear window.

Removing rear window

3. Remove rear window with the cutting wire separator. →   General information on installing and removing

car windows

Preparing window frame for installation

Removing adhesive from the body

Note

The surface coating of adhesive residue helps new adhesive to stick. Keep cut surfaces clean and free
of grease and do not clean with cleaning solution.

•

Removing adhesive from the body

1.

Diagnostic system: reading out fault memory and activating systems

Removing rear window

2582

When removing remaining adhesive -1- with the cutting tool -C- and the flashing knife -D- on the body,
ensure that a surface coating of adhesive remains -2- .

Cleaning and priming paint damage or newly built-up paint areas in the
window aperture of the body

Note

A ventilation period of at least 10 minutes must be observed between the cleaning of the glass section
and the application of the primer! No cleaning solution residues may remain on the body.

•

Clean and prime the body.

1. Clean new paint areas or damage to the top coat paint in the non-visible area of the glass section in the

body with cleaning solution -H1- and patch with primer -H2- .

Preparing rear window for installation

Removing seal for rear window

Note

Only if the window is to be re-installed.

•

Diagnostic system: reading out fault memory and activating systems

Removing adhesive from the body

2583

Pulling off seal

1. Pull off seal -3- . Remove adhesive residues with cleaning solution

-H1-

 .

Removing adhesive from the rear window

Note

Only if the rear window is to be re-installed.

•

Removing adhesive from the rear window

Note

The remaining adhesive helps new adhesive to stick. Keep cut surfaces clean and free of grease and
do not clean with cleaning solution.

•

1. Equip cutter -C- with flashing knife -D- and remove remaining adhesive from the rear window, ensuring

that a surface coating of adhesive remains.

Diagnostic system: reading out fault memory and activating systems

Removing seal for rear window

2584
