- Preliminary work
- Removing microswitch for window opening controls
- Installing microswitch for window opening controls
- Subsequent work

Preliminary work

Preliminary work

1. Remove door unit carrier. → 5730 21 Removing and installing door unit carrier - removing

Removing microswitch for window opening controls

Unclipping electric wire for micro switches

Installation Location:

2485

Overview, removing and installing door handle

Unclipping wire

1. Unclip electric wire for microswitch -1- from the bottom part of door handle -2- .

Removing microswitch for window opening controls

Installation Location:

Install location for window opening microswitch

Diagnostic system: reading out fault memory and activating systems

Unclipping electric wire for micro switches

2486

Removing microswitches

1. Unscrew fastening nuts -1- .

2. Pull bottom section of door handle -2- slightly backwards.

Note

Make sure that the locking tabs do not break when the microswitch is removed.

•

3. Gently loosen the locking tab -arrow A- and remove the microswitch -3- -arrow B- .

Installing microswitch for window opening controls

Installing microswitch for window opening controls

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing microswitch for window opening controls

2487

Install location for window opening microswitch

Installing microswitch

1. Position microswitch -3- on the door handle -4- and press in until it can be felt to engage.

2. Position the lower part of the door handle -2- under the handle and screw down with fastening nuts -1- .

Tightening torque → Final tightening: 9.7 Nm (7 ftlb.)

Clipping in the electric wire for micro switches

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Installing microswitch for window opening controls
