Opening and closing hydraulic valve To open, insert the Allen key -A- through the bore -X- of the roll-over bar module into the hydraulic valve -B- Bleeding the hydraulic system ATTENTION Damage to the convertible-top frame if not running synchronously. Bleed the hydraulic system only after the hydraulic cylinders have been removed from the • → The system has a self-bleeding feature. Three to four operations will bleed the system. After bleeding, check Subsequent work Subsequent work 1. Calibrate convertible top. → 6101K2 K2 -Calibrating convertible top in cabriolet 2. Install trim panel for convertible top rest. → 700819 Removing and installing trim panel for convertible top rest - chapter on "Installing" 3. Install rear wall trim panel → 703119 Removing and installing trim panel for rear wall - chapter on "Installing" [997310 997311 997320 997321]→ 703119 23 Removing and installing trim panel for 4. Install rear side trim panel. → 707519 Removing and installing rear side trim panel - chapter on Diagnostic system: reading out fault memory and activating systems Access for opening and closing the hydraulic valve 2333 |
