Removing cover for sliding roof

Installation Location:

Installation position for sunroof

Opening sliding-roof panel

1. Open sliding-roof panel approx. 80 mm.

2101

Disengaging slide/tilt sunroof trim

Note

The slide/tilt sunroof trim must be moved without the use of force.

2. Disengage (press) slide/tilt sunroof trim out of the left and right-hand front catches towards the rear and

out of the drivers, and push back by approx. 30 mm.

Moving sliding-roof panel to tilting position

3. Close sliding-roof panel and move to tilting position.

Slide/tilt sunroof trim

Note

The slide/tilt sunroof trim must be moved without the use of force.

4. Push slide/tilt sunroof trim back evenly on the left and right as far as it will go.

Diagnostic system: reading out fault memory and activating systems

Removing cover for sliding roof

2102

Moving sliding-roof panel to zero position

5. Move sliding-roof panel to zero position (closed).

Undoing sliding-roof panel

ATTENTION

Damage to rear water drainage channel or to the sunroof mechanism when the sliding-roof panel is
removed and when moving the slide/tilt sunroof trim.

→ Once the sliding-roof panel has been removed, the frame for the sunroof must not be moved to the

"Open" position.

6. Unscrew fastening screws and lift sliding-roof panel up and off.

Installing cover for sliding roof

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Installing cover for sliding roof

2103

Installation position for sliding-roof panel

Note

Sliding-roof panel may only be installed in the zero position in the frame for the sunroof!

•

Inserting sliding-roof panel

1. Push gate (inset) back on the left and right. Insert panel for sliding roof in the designated frame and

position fastening screws.

Diagnostic system: reading out fault memory and activating systems

Installing cover for sliding roof

2104
