Removing lid and rubber sleeve

Installation Location:

Installation position of lid and rubber sleeves

Removing lid and rubber sleeves

1. Press out the lid -1- and rubber sleeve -2- using a plastic spatula.

Removing retaining clips

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing lid and rubber sleeve

2009

Installation position of retaining clips

Removing retaining clips

1. Unclip retaining clip for electric plug connection -1- , examine it and replace if necessary.

2. Unclip retaining clip for bowden cable for power windows -2- , examine it and replace if necessary.

Removing rubber pad

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing retaining clips

2010

Installation position of rubber buffer

Note

Note that removal of the rubber buffer will damage it. It must not be reused.

•

Removing rubber buffer

1. Lever the rubber buffer -1- off the basic door frame -2- using a plastic wedge and remove it -arrow- .

Clean any residual adhesive -3- off the basic door frame using cleaning solution.

Assembling door

Installing rubber buffer

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Removing rubber pad

2011

Installation position of rubber buffer

Installing rubber buffer

1. Remove protective film -3- from rubber buffer -1- , clip rubber buffer onto basic door frame -1- and press

into position -arrow- .

Installing retaining clips

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Installing rubber buffer

2012
