Overview, removing and installing door handle

Disconnect connection piece

1. Press locking tabs -Pfeil A- and move sliding part -1- -Pfeil B- .

2. Unclip the connection piece -2- from the actuating shaft -3- .

Removing door handle and bottom part of door handle

Installation Location:

Diagnostic system: reading out fault memory and activating systems

Disconnect connection piece

1933

Overview, removing and installing door handle

Releasing the door handle

1. Unscrew fastening nuts -1- .

2. Separate bottom part of door handle -2- from door handle -3- .

Removing door handle

3. Pull door handle downward at an angle.

Diagnostic system: reading out fault memory and activating systems

Removing door handle and bottom part of door handle

1934

Unclipping support

4. Unclip

support.

Locking lock actuation

Installation Location:

Overview, removing and installing door handle

Note

To fit the lock actuation correctly, the securing spring must be hooked into the lock actuation lever
before the door lock is installed.

•

Diagnostic system: reading out fault memory and activating systems

1935

The secured position of the lock actuation is released automatically when the door handle is first
pressed. A clear clicking sound can be heard when the door handle is first pressed.

•

1. Light up inside of door with a

lamp.

Locking lock actuation

2. Guide the assembly tool T10118 -1- between the securing spring -2- and the lever -3- .

3. The securing spring -2- hooks on to the tool with a rotary

movement.

Lock actuation locked

4. Pull the securing spring -2- towards the outside of the door -Pfeil A- until the spring engages audibly in

the locking lug of the lever -3- .

5. Unhook the tool -1- and remove it.

Note

Pull carefully on the lock actuation to check that it is secured in installation position. Repeat the steps
listed above if necessary.

•

Diagnostic system: reading out fault memory and activating systems

Locking lock actuation

1936
