Diagnostic system: reading out fault memory and activating systems

Subsequent work

1445

- Preliminary work
- Removing front wheel housing liner
- Installing front wheel housing liner
- Subsequent work

Preliminary work

Preliminary work

Remove front wheel. → 440519 Removing and installing wheel - chapter on "removing"

Removing front wheel housing liner

Removing front wheel housing liner - rear section

Installation Location:

Installation position of front wheel housing liner

1446

Releasing wheel housing liner part A

Note

Fastening nuts cannot be used again following removal.

1. Unscrew fastening nuts -1- and fastening screws -2- .

2. Remove wheel housing liner

-A-

 .

Remove front wheel housing liner - front section

Installation Location:

Installation position of front wheel housing liner

Note

The front part of the wheel housing liner can also be removed without disassembling the front wheels.

Diagnostic system: reading out fault memory and activating systems

Removing front wheel housing liner - rear section

1447

Removing wheel housing liner part B

1. Unscrew fastening screws -2, 3- and remove wheel housing liner

-B-

 .

Installing front wheel housing liner

Install front wheel housing liner - front section

Installation Location:

Installation position of front wheel housing liner

Note

Push in wheel housing liner toward the outside up to contact in wing stop position.

•

Ensure that the right wheel housing liner is guided through the opening on the wheel well.

•

Diagnostic system: reading out fault memory and activating systems

Remove front wheel housing liner - front section

1448
