Main illustration for removing and installing wing Fastening tank filler neck Note The following points apply only to the right wing. • 1. Install angled pipe -8- . Press in the plastic clip -9- until the locking tabs -B- engage audibly. 2. Tighten fastening screw -6- on tank filler neck -7- . Tightening torque → Tightening torque: 7.5 ftlb. 3. Press in the locking tabs -A- of the sleeve -5- until they engage audibly. Installing fuel tank cap Installation Location: Diagnostic system: reading out fault memory and activating systems Fastening tank filler neck 1441 |
