Drive shaft 2. Fit drive shaft on transmission side. To do this, screw in the six Allen screws joining drive shaft and transmission flange and tighten screws. Location Explanation Type Basic value Tolerance 1 Tolerance 2 Drive Fastening screws between drive shaft Tightening 81 (60) Nm (ftlb.) Coolant line clips 3. Engage coolant lines on the transmission. Subsequent work Subsequent work 1. Fit the underbody panel. → 519419 Removing and installing rear cover - chapter on 2. Lower the vehicle. 997110, 997111, 997120, 997121, 997310, 997311, 997320, 997321, 997410, 997411, 997430, 997431, Diagnostic system: reading out fault memory and activating systems Installing halfshaft flange 1077 |
