Diagnostic system: reading out fault memory and activating systems

Subsequent work

973

- Preliminary work
- Removing selector lever cable
- Installing selector lever cable
- Subsequent work

Preliminary work

Preliminary work

1. Move selector lever to position P.

2. Raise the vehicle at the prescribed jacking points. →   Raising the vehicle

3. Remove underbody panel. → 519419 Removing and installing the rear cover - removing→ 519320

21  Removing and installing the middle cover - removing

Removing selector lever cable

Removing selector lever cable from transmission

Transmission support

1. Remove transmission support.

974

Pinion shaft cover

2. Remove plastic cover -A- around pinion shaft.

Disengaging selector lever cable

3. Lever off selector lever cable on transmission control with a screwdriver and disengage selector lever

cable from support.

Detaching selector lever cable inside vehicle

1. Remove selector knob. → 370419 Removing and installing selector knob - chapter on "removing"

2. Remove centre console. → 681719 Removing and installing centre console - chapter on "removing"

3. Loosen parking-brake lever. → 466119 21 Removing and installing parking-brake lever - chapter on

"Removing"

Bajonettverschluss öffnen

4. Open bayonet lock.

Diagnostic system: reading out fault memory and activating systems

Removing selector lever cable from transmission

975

Disengaging the selector cable

5. Detach adjustment pins.

Widerlager ausklipsen

6. Unclip support bracket at selector frame.

Rubber sleeve

7. Bend up the tabs -A- at the body opening and push the rubber sleeve outward through the body

opening.

Installing selector lever cable

Fastening selector lever cable on transmission

Diagnostic system: reading out fault memory and activating systems

Detaching selector lever cable inside vehicle

976
