Installing rear silencer

Note

Replace clamping sleeve, seal and lock nuts. Apply a light coating of high-temperature grease on the
sleeve before installation to facilitate fitting.

•

1. Fit new clamping sleeve. To do this, slide the clamping sleeve onto the catalytic-converter pipe.

Position at which rear silencer is screwed to holder

2. Insert the silencer into the vehicle from the wheel side and move it to installation position. Then fit three

new hexagon nuts on the screw connection points of the holder and tighten only slightly.

Installation position of clamping sleeve

3. Slide the clamping sleeve over the silencer pipe and move it to installation position → Installation

position of clamping sleeve . Screw down both hexagon nuts and tighten to the prescribed torque. →
Tightening torque: 23 (17 ftlb.) Nm

4. Tighten three hexagon nuts on the rear silencer holder. → Tightening torque: 23 (17 ftlb.) Nm

5. Fit and adjust tailpipe. → Tightening torque: 30 (22 ftlb.) Nm → 263419 Removing and

installing tailpipe - section on "Installing" [997110 997111 997310 997311 997410 997411
997610 997611]→ 263419 Removing and installing tailpipe - section on "Installing" [997120
997121 997320 997321 997430 997431 997620 997621].

Diagnostic system: reading out fault memory and activating systems

Installing rear silencer

769

Subsequent work

Rear spoiler support

1. Fit strut for rear apron and tighten screws. → Tightening torque: 3 (2 ftlb.) Nm , → Tightening torque:

10 (7.5 ftlb.) Nm

2. Mount rear wheel. Use a socket wrench insert P 300 to avoid damage to the wheel rims → 440519

Removing and installing wheel - section on "Installing".

997110, 997111, 997120, 997121, 997310, 997311, 997320, 997321, 997410, 997411, 997430, 997431,
997610, 997611, 997620, 997621

WARNUNG

Gefahr des Verlusts der Text-Bild-Zuordnung beim Ausdruck.

Aus technischen Gründen kann derzeit nicht ausgeschlossen werden, dass trotz
einwandfreier Darstellung auf dem Bildschirm beim Ausdruck der
Zusammenhang von Text und zugehörigem Bild verloren geht.

•

Wird der Fehler nicht bemerkt, besteht die Gefahr, daß Arbeiten nicht korrekt
durchgeführt werden und es dadurch zu Personen- und Sachschäden kommt.

•

→ Vergleichen Sie deshalb nach dem Druckvorgang unbedingt die Ausdrucke mit der
Bildschirmdarstellung. Korrigieren Sie die Ausdrucke im Fehlerfall so, daß der Inhalt der
Bildschirmdarstellung zutreffend wiedergegeben wird.

Diagnostic system: reading out fault memory and activating systems

Subsequent work

770

WARNING

Danger of losing text-figure correspondence when printing out.

For technical reasons, it can currently not be ruled out that the correspondence
between text and associated figure can be lost when it is printed out, even though
the display on the screen is correct.

•

If the fault is not noticed, there is the danger that work will not be performed
correctly which can cause injury and damage.

•

→ Therefore, always compare printouts with the screen display after printing them out. Correct
the printouts if they are faulty so that the content of the screen display matches that on the
printouts.

AVERTISSEMENT

Risque de perte de la correspondance texte-illustration lors de l'impression papier.

Pour des raisons techniques, il ne peut pas être exclu à l'heure actuelle que, même
en cas d'affichage correct à l'écran, la correspondance entre le texte et l'illustration
puisse être erronée sur l'impression papier.

•

Si l'erreur passe inaperçue, on court le risque d'exécuter certaines opérations de
manière incorrecte pouvant conduire à des dommages corporels et matériels.

•

→ Comparez impérativement pour cette raison les impressions papier avec l'affichage à l'écran.
Corrigez-les en cas d'erreur de manière à reproduire correctement l'affichage à l'écran.

ATTENZIONE

Pericolo di perdita dell'abbinamento testo-immagine nella stampa.

Per motivi tecnici non è escluso che, nonostante la rappresentazione sullo schermo
risulti perfetta, durante la stampa venga persa la corrispondenza fra testo e
relativa immagine.

•

Se tale difetto non viene rilevato vi è il pericolo che i lavori non siano eseguiti
correttamente; ciò può avere come conseguenza lesioni e danneggiamenti.

•

→ Per questo motivo, dopo la stampa è assolutamente necessario confrontare le stampe con la
rappresentazione sullo schermo. In caso di errore si prega di correggere le stampe, così da
garantire la riproduzione esatta della rappresentazione sullo schermo.

ADVERTENCIA

Al imprimir se corre el riesgo de perder la correcta asignación de las figuras al texto.

Por motivos técnicos, por el momento no se puede descartar que, aun siendo
correcta la imagen que aparezca en la pantalla, al imprimir se pierda la
correlación entre el texto y la figura correspondiente.

•

Si este error pasara desapercibido, existe el riesgo de que los trabajos no se
ejecuten de forma correcta y, por tanto, se produzcan daños personales y

•

Diagnostic system: reading out fault memory and activating systems

Subsequent work

771

materiales.

→ Por ello le rogamos que tras el proceso de impresión compare siempre las copias impresas con
la imagen de la pantalla. En caso de error, corrija las copias impresas de forma que se
correspondan con el contenido de la imagen de la pantalla.
