Read out vehicle data. → 247019 Removing and installing DME control module - "Preliminary
work" section

4. Carry out automatic search of control units.

5. Select DME with the cursor keys and press the >> key.

6. Select Program control unit with the cursor keys and press the >> key.

7. Select Program control modules with the cursor keys and press the >> key. Observe the

information displayed by the Tester.

8. Enter Vehicle Ident. No., >> confirm with F7 .

9. Enter the old DME programming code (IPAS) , >> confirm with F7 .

10. Enter the new DME programming code (IPAS) , >> confirm with F7 .

11. Enter the old immobiliser code (IPAS) , >> confirm with F7 .

12. Enter the new immobiliser code (IPAS) , >> confirm with F7 .

13. Specify vehicle type >> .

14. Specify transmission type >> .

15. Specify exhaust standard >> .

16. Start Programming with F8 . The data and programming status is then loaded on to the DME control

module. Do not interrupt the programming sequence. Observe Tester instructions.

17. For the learning and adaptation routine of the throttle valve (electronic throttle), switch the ignition off,

remove ignition key, insert ignition key and switch on ignition for at least 40 seconds without starting the
engine. Do not actuate accelerator pedal. This completes the adaptation of the throttle adjusting unit and
the programming sequence is complete.

18. In the DME menu go to Coding, code Cruise control present, not

present.

19. Go to Vehicle data and, if necessary, enter the vehicle-specific data.

20. Read out the fault memories of all control units and delete the DME control module fault on every

control unit connected to the CAN.

21. Start engine.

22. Carry out a test drive and read out fault memory again.

Exhaust-gas standard

ME 7.8

Type

Exhaust-gas standard

Explanation

OBD 2

LEV, manual transmission

LEV, Tiptronic

Low Emission Vehicle, USA
As of model year `03.

RoW

EU2, manual transmission

EU2, Tiptronic

Rest of world
As of model year `03.

EOBD EU4, manual transmission European On-Board Diagnosis.

As of model year `05.

Diagnostic system: reading out fault memory and activating systems

Exhaust-gas standard

745

EU4, Tiptronic

Corea

EU4, manual transmission

EU4, Tiptronic

For Corea, as of model year '05.

Japan

EU4, manual transmission

EU4, Tiptronic

For Japan, as of model year '05.

997110, 997111, 997120, 997121, 997410, 997411, 997430, 997431
