. Cutting off ABS wire harness Note When cutting the ABS wire harness, make sure that there is enough line length left to join to the new lines. 4. Cut off the ABS wire harness around -a- and press inward with the rubber sleeve -b- -arrow- . Cutting off rubber sleeve Note Only for vehicles with HBA. 5. Cut through the rubber sleeve at the side of the HBA line -a- and remove the HBA line -arrow- . Installing wire harness for anti-lock brake system (ABS) Installing front ABS wire harness Diagnostic system: reading out fault memory and activating systems Installing wire harness for anti-lock brake system (ABS) 4457 |
