Securing ground point 19. Fasten ground point -4- at left and right. 19.1. Connect ground straps and screw down fastening nut. → Tightening torque: 9 (6.5 ftlb.) Nm Pushing connector onto fuse box for fan 20. Push connector onto fuse box for fan -2- . 20.1. Push connector onto fuse box for fan -Arrow A- . 20.2. Close lid -Arrow B- until it is felt to engage. 20.3. Position fuse box below on the clip -Arrow C- and clip in -Arrow D- . Pushing together plug connection between front end wire harness and main wire harness, right 21. Push together plug connection between front end wire harness and main wire harness, right -1- . 21.1. Push together plug connection between front end wire harness and main wire harness, right and lock -Arrow B- until it is felt to engage. Diagnostic system: reading out fault memory and activating systems Installing wire harness for front-end 4305 |
